LT-CN12G801W, LT-CN14G801W, LT-CN32G801W, LT-CN34G801W, LT-CN35G102W
LT-CN12G801W
LT-CN14G801W
LT-CN32G801W
LT-CN34G801W
LT-CN35G102W
| Type | LT-CN12G801W | LT-CN14G801W | LT-CN32G801W | LT-CN34G801W | LT-CN35G102W |
|---|---|---|---|---|---|
| SPD according to EN 61643-11 /IEC 61643-11 |
type2 ClassⅡ |
||||
| Nominal a.c. voltage (Un) | 250V (50 / 60 Hz) |
L-E : 250V L-L : 430V (50 / 60 Hz) |
3ΦY : 250V 3ΦΔ : 250V (50 / 60 Hz) |
3ΦY : 430V 3ΦΔ : 250V (50 / 60 Hz) |
3ΦY : 500V 3ΦΔ : 290V (50 / 60 Hz) |
| Max. continuous operating a.c. voltage (Uc) |
275V (50 / 60 Hz) |
L-E : 280V L-L : 480V (50 / 60 Hz) |
3ΦY : 275V 3ΦΔ : 275V (50 / 60 Hz) |
3ΦY : 480V 3ΦΔ : 280V (50 / 60 Hz) |
3ΦY : 550V 3ΦΔ : 320V (50 / 60 Hz) |
| Nominal discharge current (8/20μs) (In) | 2.5kA | ||||
| Max.discharge current (8/20μs) (Imax) | 5kA | ||||
| Voltage protection level (Up) | ≦1.5kV | ≦1.8kV | ≦1.5kV | ≦1.8kV | ≦2.0kV |
| Response time | L-L : ≦3ns | ||||
| Application system | 1 phase | 3 phase | |||
| mode of protection | Common & Differential Mode | ||||
| Operating temperature range (Tu) | -20℃～ +60℃ | ||||
| Operating state / fault indication | Green / red | ||||
| Cross-sectional area | AWG14×250mm | ||||
| For mounting on | M4 screw | ||||
| Enclosure material | thermoplastic, UL 94 V-0 | ||||
| Place of installation | Indoor installations | ||||
| Degree of protection | IP 20 | ||||
| Certification | UL1449 Listing / NFPA79 / CSA / TUV | ||||
